Instruments

All series pressure gauges and pressure transmitters are available

Process

connection

(Thread)

1/4” ； 3/8” ； 1/2” ； 3/4” ； 1” PT (BSPT) / NPT, male or female thread

Other connection available made-to-order.

Note: Generally PF (BSP) thread is not available because the inlet hole is too small and it will be clogged with viscous or crystallizing medium.

Diaphragm

housing

(in one body)

Material: SS304 ; SS316 ; SS316L

Diameter 70 mm standard, 90 mm available

Diaphragm

SS316L

Coating (option)

Teflon ; PFA

Temperature

medium +80°C ； ambient 10 to 60°C

for medium 80~400°C or ambient below 10°C available made-to-order

Filling fluid

Glycerin or silicon oil standard (depends on temperature), fluorocarbon oil available

Pressure ranges

General type: 0/1 -0/60 kg/cm2 (bar), positive, negative or compound High pressure type: 0 / 70 〜0 / 600 kg/cm2 (bar)

Accessory

assembly

(option)

Cooling fin

Capillary for remote measurement (specify length of capillary when ordering)
